HDMI/DVI/VGA over IP Transmission

HKM02BPT-4K 4K HDMI KVM & USB, RS232 , IR, Audio Transmitter with PoE
HKM02BPR-4K 4K HDMI KVM & USB, RS232 , IR, Audio Receiver with PoE
HKM02BT-4K 4K HDMI KVM & USB, RS232 , IR, Audio Transmitter
HKM02BR-4K 4K HDMI KVM & USB, RS232 , IR, Audio Receiver
• Transmitter built-in HDMI loop out
【Specification】
Cable: CAT5e UTP or higher or SFP optical fiber
Resolution: up to 4K 30Hz 4:4:4 (Max)
HKM02BPR-4K HKM02BPT-4K
HKM02BR-4K HKM02BT-4K

HKM02BT 1080p HDMI KVM & USB, RS232 , IR, Audio Transmitter
HKM02BR 1080p HDMI KVM & USB, RS232 , IR, Audio Receiver
• Transmitter built-in HDMI loop Out
【Specification】
Cable: CAT5e UTP or higher
Resolution: up to 1080p 60Hz (Max)
HKM02BT HKM02BR
VDKM02BT VGA/DVI KVM & USB, RS232 , IR, Audio Transmitter
VDKM02BR VGA/DVI KVM & USB, RS232 , IR, Audio Receiver
• Transmitter built-in both DVI and VGA loop out
• Receiver support DVI & VGA output at the same time.
【Specification】
Cable: CAT5e UTP or higher VDKM02BT VDKM02BR
Resolution: up to 1920x1200 60Hz (Max)
TPN002BT Fit 2 pcs of HKM02BT-4K Transmitter Unit

TPN002BT

TPN003BT Fit 3 pcs of HKM02BT Transmitter Unit

TPN003BT
TPN002VD Fit 2 pcs of VDKM02BT Transmitter Unit

TPN002VD

PR1008-5R 10A 8 Port DC5V Regulated Power Supply in 1U Rack
To send regulated DC5V power to multiple HKM02B, VDKM02B

PR1008-5R

PR816-12R 8A 16 Port DC12V Regulated Power Supply in 1U Rack
To send regulated DC12V power to multiple HKM02B-4K

PR816-12R

KC01 External RS232 Keypad
Easily switch the channel of receiver
