Power Center

PW408S 4A 8 Port Dual Power Supply PW408S-12R 4A 8 Port DC12V Regulated
To transform AC110V or 230V to 8 port of DC12Vor AC24V output. Power Supply
• Built-in PTC fuse rated 1.1A for short protection and auto rework Identical to PW408S, but support regulated DC12V output.
on each port. 【Specification】
• Built-in toroidal transformer for high efficiency and low operating Power input: AC 120V or 230V
temperature.
• Wall mounting metal box Power output: Regulated DC12V 4A (Total),
【Specification】 each port 1.1A (MAX)
Dimension: 224 x 200 x 60 mm
Power input: AC 120V or 230V
Power output: DC12V AC24V 4A (Total),
each port 1.1A (MAX)
Dimension: 224 x 200 x 60 mm PW408S PW408S-12R
PW816S-AC24 8A 16 Port AC24V PW816S-12R 8A 16 Port DC12V Regulated
Power Supply Power Supply
To transform AC110V- 240V to 16 port of AC24V 0.5A output. Identical to PW816S-AC24, but support regulated DC12V output.
• Built-in PTC fuse rated 1.1A for short protection and auto 【Specification】
rework on each port. Power input: AC 100V- 240V
• Built-in toroidal transformer for high efficiency Power output: Regulated DC12V 8A (Total),
and low operating temperature. each port 1.1A (MAX)
• Wall mounting metal box Dimension: 224 x 200 x 60 mm
【Specification】
Power input: AC 100V- 240V
Power output: AC24V 8A (Total),
each port 1.1A (MAX)
Dimension: 224 x 200 x 60 mm PW816S-AC24 PW816S-12R
Power Adapter

SWP051000 DC5V 1A Switching Power Adapter SWP052000 DC5V 2A Switching Power Adapter
【Specification】 【Specification】
Power input: AC 90V- 240V Power input: AC 90V- 240V
Power output: Regulated DC5V 1A Power output: Regulated DC5V 2A
SWP051000 SWP052000

SWP12500 DC12V 0.5A Switching Power Adapter SWP121000 DC12V 1A Switching Power Adapter
【Specification】 【Specification】
Power input: AC 90V- 240V Power input: AC 90V- 240V
Power output: Regulated DC12V 0.5A Power output: Regulated DC12V 1A SWP121000
SWP12500

SWP121500 DC12V 1.5A Switching Power Adapter SWP124200 DC12V 4.2A Switching Power Adapter
【Specification】 • Desktop type.
Power input: AC 90V- 240V 【Specification】
Power output: Regulated DC12V 1.5A Power input: AC 90V- 240V
Power output: Regulated DC12V 4.2A SWP124200
SWP121500

SWP241250 DC24V 1.25A Switching Power Adapter SWP480830 DC48V 0.83A Switching Power Adapter
【Specification】 • Desktop type.
Power input: AC 90V- 240V 【Specification】
Power output: Regulated DC24V 1.25A Power input: AC 90V- 240V
SWP241250 Power output: Regulated DC48V 4.2A SWP480830

SWP561600 DC56V 1.6A Switching Power Adapter
• Desktop type.
【Specification】
Power input: AC 90V- 240V SWP561600
Power output: Regulated DC56V 1.6A
Power Surge Protector

SP001P-AC110 AC Power Surge Protection Device Terminal Connector
To provide surge protection for a AC100-120V device.
【Specification】
Connector: Terminal connector to terminal connector. SP001P-AC110
Response time: < 1ns Max discharge current: 6kA (8x20uS)
Max load current: 8A (Max) Breakdown voltage: 6kV (1.2uS x 50uS)
SP001P-AC220 AC Power Surge Protection Device Terminal Connector
To provide surge protection for a AC220-240V.
【Specification】
Connector: Terminal connector to terminal connector. SP001P-AC220
Response time: < 1ns Max discharge current: 6kA (8x20uS)
Max load current: 4A (Max) Breakdown voltage: 6kV (1.2uS x 50uS)
