HD-TVI/AHD/HDCVI/CVBS Transmission

Power Ground Loop Isolator
GL001HP HD-TVI/AHD/HDCVI/CVBS Power Isolator 600mA
To eliminate ground loop which is caused by power cables laid together with video/data cables.
• Support UTC data control (Up The Coax)
【Specification】
Power Input: DC12V-DC24V GL001HP
Power Output: DC12V 600mA
GL001HP-1A HD-TVI/AHD/HDCVI/CVBS Power Isolator 1A
Identical to above GL001HP, but support power output to 1A.

GL001HP-1A

Video Transformer Filter

Before Use After Use

CB001VH Coaxial Balun for DVR
Built-in a highly balanced mode of video transmission, which is immune to interference from these,
and other sources of noise: Data signals, other video signals, nearby power, ringing telephones,
fluorescent lights, transformers, and more...
【Specification】
Video format: CVBS CB001VH
Connector: BNC male to BNC female 75Ω

TVB001 Twisted Pair Video Balun
Eliminate interference under long range cabling caused by “Impedance matching”, add TVB001
at “connecting point” between two-wire connections for compensation.
【Specification】
Video format: CVBS
Connector: twisted pair TVB001

High Frequency Interference Blocker

Before Use After Use

CHB001HM High Frequency Interference Blocker Solution
To eliminate high frequency interference on NTSC/PAL Video.
16 channels video or video & audio transmits over one coaxial cable
• Perfect solution for elevator, high voltage, heavy power interference.
【Specification】
Max transmission distance: 400 meters (RG59)

CHB001HMT CHB001HMR
