HD-TVI/AHD/HDCVI/CVBS Transmission

Coaxial Cabling Solution
Distributor/Distribution Amplifier
CD102HD 1 x 2 HD-TVI/AHD/HDCVI/CVBS Video Distributor
1 video input to 2 video output.
• Built-in TVS protection
【Specification】
Resolution: up to 4K
Coaxial 500M(720P) / 200M(1080p)
Coaxial 100M (MAX)
HD Source
HD DVR
CD102HD
CD102A 1 x 2 CVBS Video Distribution Amplifier
1 video input to 2 video output with amplifier function
• 10dB adjustable image gain.
• HF compensation.
• Sharpness and brightness adjustment
【Specification】
Transmission distance: 1000 meters (RG59)
CD102A

CD104HD 1 x 4 HD-TVI/AHD/HDCVI/CVBS Video Distributor
1 video input to 4 video output.
• Support UTC data control (Up The Coax).
• Built-in TVS protection.
【Specification】 Coaxial 100M (MAX)
Resolution: up to 4K
CD104HD
Coaxial 500M(720P) / 200M(1080p)

HD Source
HD DVR

CD108HD 1 x 8 HD-TVI/AHD/HDCVI/CVBS Video Distributor
1 video input to 8 video output.
• Support UTC data control (Up The Coax).
• Built-in TVS protection.
【Specification】
Resolution: up to 4K
CD108HD

CD408HD 4 x 8 HD-TVI/AHD/HDCVI/CVBS Video Distributor
4 video input to 8 video output.
• Support UTC data control (Up The Coax).
• Built-in TVS protection.
【Specification】
Resolution: up to 4K

CD408HD

CD816HD 8 x 16 HD-TVI/AHD/HDCVI/CVBS Video Distributor in 1U Rack
8 video input to 16 video output.
• Built-in TVS protection.
【Specification】
Resolution: up to 4K

CD816HD

CD1632HD 16 x 32 HD-TVI/AHD/HDCVI/CVBS Video Distributor in 1U Rack
16 video input to 32 video output.
• Built-in TVS protection.
【Specification】
Resolution: up to 4K

CD1632HD
